TECHNICAL PARAMETERS
| Model | ASS-6 | ASS-7 | ASS-8 | ASS-9 |
|---|---|---|---|---|
| Working Width (mm) Approx | 1700 | 2000 | 2300 | 2600 |
| Tractor Power (HP) | 40–50 | 55 Above | 60 Above | 65 Above |
| No. of Blades | 48 | 54 | 60 | 66 |
| Blades Type | LJF TYPE | |||
| Thickness of Blades (mm) | 7–8 mm | |||
| Gear Box | Multi Speed 11:22 | |||
| Side Drive | Gear Drive 21:36:26 | |||
| Seed & Fertilizer Mechanism | Aluminium Fluted Roller Type | |||
| Press Roller | Available | |||
| No. of Tynes | 9+1 | 11+1 | 13+1 | 15+1 |
| Weight (Kg.) | 950 | 1000 | 1150 | 1250 |
